-# Introduction to Components
|
|
|
-
|
|
|
-In the previous chapter, we learned about Elements and how they can be composed to create a basic User Interface. In this chapter, we'll learn how to group Elements together to form Components.
|
|
|
-
|
|
|
-In this chapter, we'll learn:
|
|
|
-- What makes a Component
|
|
|
-- How to model a component and its properties in Dioxus
|
|
|
-- How to "think declaratively"
|
|
|
-
|
|
|
-## What is a component?
|
|
|
-
|
|
|
-In short, a component is a special function that takes input properties and outputs an Element. Typically, Components serve a single purpose: group functionality of a User Interface. Much like a function encapsulates some specific computation task, a Component encapsulates some specific rendering task.
|
|
|
-
|
|
|
-### Learning through prior art
|
|
|
-
|
|
|
-Let's take a look at a post on r/rust and see if we can sketch out a component representation.
|
|
|
-
|
|
|
-
|
|
|
-
|
|
|
-This component has a bunch of important information:
|
|
|
-
|
|
|
-- The score
|
|
|
-- The number of comments
|
|
|
-- How long ago it was posted
|
|
|
-- The url short address
|
|
|
-- The title
|
|
|
-- The username of the original poster
|
|
|
-
|
|
|
-If we wanted to sketch out these requirements in Rust, we would start with a struct:
|
|
|
-
|
|
|
-```rust
|
|
|
-struct PostData {
|
|
|
- score: i32,
|
|
|
- comment_count: u32,
|
|
|
- post_time: Instant,
|
|
|
- url: String,
|
|
|
- title: String,
|
|
|
- original_poster_name: String
|
|
|
-}
|
|
|
-```
|
|
|
-
|
|
|
-If we look at the layout of the component, we notice quite a few buttons and pieces of functionality:
|
|
|
-
|
|
|
-- Upvote/Downvote
|
|
|
-- View comments
|
|
|
-- Share
|
|
|
-- Save
|
|
|
-- Hide
|
|
|
-- Give award
|
|
|
-- Report
|
|
|
-- Crosspost
|
|
|
-- Filter by site
|
|
|
-- View article
|
|
|
-- Visit user
|
|
|
-
|
|
|
-If we included all this functionality in one `rsx!` call it would be huge! Instead, let's break the post down into some core pieces:
|
|
|
-
|
|
|
-
|
|
|
-
|
|
|
-- **VoteButton**: Upvote/Downvote
|
|
|
-- **TitleCard**: Title, Filter-By-Url
|
|
|
-- **MetaCard**: Original Poster, Time Submitted
|
|
|
-- **ActionCard**: View comments, Share, Save, Hide, Give award, Report, Crosspost
|
|
|
-
|
|
|
-### Modeling with Dioxus
|
|
|
-
|
|
|
-We can start by sketching out the Element hierarchy using Dioxus. In general, our "Post" component will be comprised of the four sub-components listed above. First, let's define our `Post` component.
|
|
|
-
|
|
|
-Unlike normal functions, Dioxus components must explicitly define a single struct to contain all the inputs. These are commonly called "Properties" (props). Our component will be a combination of these properties and a function to render them.
|
|
|
-
|
|
|
-Our props must implement the `Props` trait and - if the component does not borrow any data - `PartialEq`. Both of these can be done automatically through derive macros:
|
|
|
-```rust
|
|
|
-#[derive(Props, PartialEq)]
|
|
|
-struct PostProps {
|
|
|
- id: Uuid,
|
|
|
- score: i32,
|
|
|
- comment_count: u32,
|
|
|
- post_time: Instant,
|
|
|
- url: String,
|
|
|
- title: String,
|
|
|
- original_poster: String
|
|
|
-}
|
|
|
-```
|
|
|
-
|
|
|
-And our render function:
|
|
|
-```rust
|
|
|
-fn Post(cx: Scope<PostProps>) -> Element {
|
|
|
- cx.render(rsx!{
|
|
|
- div { class: "post-container"
|
|
|
- VoteButton {
|
|
|
- score: cx.props.score,
|
|
|
- }
|
|
|
- TitleCard {
|
|
|
- title: cx.props.title,
|
|
|
- url: cx.props.url,
|
|
|
- }
|
|
|
- MetaCard {
|
|
|
- original_poster: cx.props.original_poster,
|
|
|
- post_time: cx.props.post_time,
|
|
|
- }
|
|
|
- ActionCard {
|
|
|
- post_id: cx.props.id
|
|
|
- }
|
|
|
- }
|
|
|
- })
|
|
|
-}
|
|
|
-```
|
|
|
-
|
|
|
-When declaring a component in `rsx!`, we can pass in properties using the traditional Rust struct syntax. Our `Post` component is simply a collection of smaller components wrapped together in a single container.
|
|
|
-
|
|
|
-Let's take a look at the `VoteButton` component. For now, we won't include any interactivity - just the rendering the score and buttons to the screen.
|
|
|
-
|
|
|
-Most of your Components will look exactly like this: a Props struct and a render function. Every component must take a `Scope` generic over some `Props` and return an `Element`.
|
|
|
-
|
|
|
-As covered before, we'll build our User Interface with the `rsx!` macro and HTML tags. However, with components, we must actually "render" our HTML markup. Calling `cx.render` converts our "lazy" `rsx!` structure into an `Element`.
|
|
|
-
|
|
|
-```rust
|
|
|
-#[derive(PartialEq, Props)]
|
|
|
-struct VoteButtonProps {
|
|
|
- score: i32
|
|
|
-}
|
|
|
-
|
|
|
-fn VoteButton(cx: Scope<VoteButtonProps>) -> Element {
|
|
|
- cx.render(rsx!{
|
|
|
- div { class: "votebutton"
|
|
|
- div { class: "arrow up" }
|
|
|
- div { class: "score", "{cx.props.score}"}
|
|
|
- div { class: "arrow down" }
|
|
|
- }
|
|
|
- })
|
|
|
-}
|
|
|
-```
|
|
|
-
|
|
|
-## Borrowing
|
|
|
-
|
|
|
-You can avoid clones by using borrowed component syntax. For example, let's say we passed the `TitleCard` title as an `&str` instead of `String`. In JavaScript, the string would be copied by reference - none of the contents would be copied, but rather the reference to the string's contents are copied. In Rust, this would be similar to calling `clone` on `Rc<str>`.
|
|
|
-
|
|
|
-Because we're working in Rust, we can choose to either use `Rc<str>`, clone `Title` on every re-render of `Post`, or simply borrow it. In most cases, you'll just want to let `Title` be cloned.
|
|
|
-
|
|
|
-To enable borrowed values for your component, we need to add a lifetime to let the Rust compiler know that the output `Element` borrows from the component's props.
|
|
|
-
|
|
|
-```rust
|
|
|
-#[derive(Props)]
|
|
|
-struct TitleCardProps<'a> {
|
|
|
- title: &'a str,
|
|
|
-}
|
|
|
-
|
|
|
-fn TitleCard<'a>(cx: Scope<'a, TitleCardProps<'a>>) -> Element {
|
|
|
- cx.render(rsx!{
|
|
|
- h1 { "{cx.props.title}" }
|
|
|
- })
|
|
|
-}
|
|
|
-```
|
|
|
-
|
|
|
-For users of React: Dioxus knows *not* to memoize components that borrow property fields. By default, every component in Dioxus is memoized. This can be disabled by the presence of a non-`'static` borrow.
|
|
|
-
|
|
|
-This means that during the render process, a newer version of `TitleCardProps` will never be compared with a previous version, saving some clock cycles.
|
|
|
-
|
|
|
-## The inline_props macro
|
|
|
-
|
|
|
-Yes - *another* macro! However, this one is entirely optional.
|
|
|
-
|
|
|
-For internal components, we provide the `inline_props` macro, which will let you embed your `Props` definition right into the function arguments of your component.
|
|
|
-
|
|
|
-Our title card above would be transformed from:
|
|
|
-
|
|
|
-```rust
|
|
|
-#[derive(Props, PartialEq)]
|
|
|
-struct TitleCardProps {
|
|
|
- title: String,
|
|
|
-}
|
|
|
-
|
|
|
-fn TitleCard(cx: Scope<TitleCardProps>) -> Element {
|
|
|
- cx.render(rsx!{
|
|
|
- h1 { "{cx.props.title}" }
|
|
|
- })
|
|
|
-}
|
|
|
-```
|
|
|
-
|
|
|
-to:
|
|
|
-
|
|
|
-```rust
|
|
|
-#[inline_props]
|
|
|
-fn TitleCard(cx: Scope, title: String) -> Element {
|
|
|
- cx.render(rsx!{
|
|
|
- h1 { "{title}" }
|
|
|
- })
|
|
|
-}
|
|
|
-```
|
|
|
-
|
|
|
-Again, this macro is optional and should not be used by library authors since you have less fine-grained control over documentation and optionality.
|
|
|
-
|
|
|
-However, it's great for quickly throwing together an app without dealing with *any* extra boilerplate.
|
|
|
-
|
|
|
-## The `Scope` object
|
|
|
-
|
|
|
-Though very similar to React, Dioxus is different in a few ways. Most notably, React components will not have a `Scope` parameter in the component declaration.
|
|
|
-
|
|
|
-Have you ever wondered how the `useState()` call works in React without a `this` object to actually store the state?
|
|
|
-
|
|
|
-React uses global variables to store this information. Global mutable variables must be carefully managed and are broadly discouraged in Rust programs.
|
|
|
-
|
|
|
-```javascript
|
|
|
-function Component(props) {
|
|
|
- let [state, set_state] = useState(10);
|
|
|
-}
|
|
|
-```
|
|
|
-
|
|
|
-
|
|
|
-Because Dioxus needs to work with the rules of Rust it uses the `Scope` object to maintain some internal bookkeeping. That's what the `Scope` object is: a place for the component to store state, manage listeners, and allocate elements. Advanced users of Dioxus will want to learn how to properly leverage the `Scope` object to build robust and performant extensions for Dioxus.
|
|
|
-
|
|
|
-```rust
|
|
|
-fn Post(cx: Scope<PostProps>) -> Element {
|
|
|
- cx.render(rsx!("hello"))
|
|
|
-}
|
|
|
-```
|
|
|
-## Moving forward
|
|
|
-
|
|
|
-Next chapter, we'll talk about composing Elements and Components across files to build a larger Dioxus App.
|
|
|
-
|
|
|
-For more references on components, make sure to check out:
|
|
|
-
|
|
|
-- [Components in depth]()
|
|
|
-- [Lifecycles]()
|
|
|
-- [The Scope object]()
|
|
|
-- [Optional Prop fields]()
|
|
|
-
|
